SHENZHEN JINGHONG INDUSTRIAL CO., LTD
Brand Name: OEM
Model Number: PCB1610
Number of Layers: 4-Layer
Base Material: FR-4
Copper Thickness: 0.5OZ
Board Thickness: 1.2mm
Min. Hole Size: 0.25mm
Min. Line Width: 0.2mm
Min. Line Spacing: 0.2mm
Surface Finishing: LEAD FREE HAL
Product name: pcb production
Layer(MAX): 2-18
Board Material: FR-4
Max board size: 1200mm*600mm
Outline size tolerance: +/- 0.13mm
profiling punching: Routing, V-CUT, Beveling
Wrap and twist: 5%
PCB Standard: IPC-A-610 E Class II-III
PCB Tolerance of finished thickness: ±5%
Solder mask: green/black/white/red/blue/yellow
Article | Description | Capability |
Material | Laminate materials | FR4,Alu,CEM3,Taconic,Rogers |
Board cutting | Number of layers | 1-58 |
Min. Thickness for inner layers (Cu thickness are excluded) | 0.003”(0.07mm) | |
Board thickness | Standard | 0.04-0.16”±10%(0.1-4mm±10%) |
Min. | Single/Double layer: 0.008±0.004” | |
4 layer: 0.01±0.008” | ||
8 layer: 0.01±0.008” | ||
Bow and twist | <7/1000 | |
Copper weight | Outer Cu weight | 0.5-4 oz |
Inner Cu weight | 0.5-3 oz | |
Drilling | Min size | 0.0078” (0.2mm) |
Drill deviation | ±0.002” (0.05mm) | |
PTH hole tolerance | ±0.002” (0.005mm) | |
NPTH hole tolerance | ±0.002” (0.005mm) | |
Plating | Min hole size | 0.0008” (0.02mm) |
Aspect ratio | 20 (5:1) | |
Solder mask | Color | Green,white,black,red,yellow,blue... |
Min solder mask clearanace | 0.003” (0.07mm) | |
Thickness | 0.0005-0.0007”(0.012-0.017mm) | |
Silkscreen | Color | White,black,yellow,red,blue... |
Min size | 0.006” (0.15mm) | |
E-test | Flying Probe Tester | Y |
Controlled Impedance | Tolerance | ±10% |
Impedance tester | Tektronix TDS8200 | |
Surface Finish | HASL,ENIG,immersion silver,immersion tin,OSP... | |
